Goodrive270 series VFD for fan and pump Function parameter list
-153-
Function
code
Name Description Default
Modify
is a percentage in relative to the rated current
of
the motor.
Setting range: 0.0±200.0%
P04.47
Proportional
coefficient in IF
mode for AM 2
When IF control is adopted for AM 2, the function
code is used to set the proportional coefficient of
output current closed
-loop control.
Setting range: 0±5000
350 ƻ
P04.48
Integral coefficient in
IF mode for AM 2
When IF control is adopted for AM 2, the function
code is used to set the integral coefficient of
output current closed
-loop control.
Setting range: 0±5000
150 ƻ
P04.49
Starting frequency
point for switching
off IF mode for AM 2
0.00
±P04.51 10.00Hz ƻ
P04.50
End frequency point
for switching off IF
mode for AM 1
P04.44
±P00.03 25.00Hz ƻ
P04.51
End frequency point
for switching off IF
mode for AM 2
P04.49
±P00.03 25.00Hz ƻ
P04.52
VF energy-saving
mode selection
0: Max. efficiency
1: Optimal power factor
2: MTPA
0 ƻ
P04.53
Energy-
saving gain
coefficient
0.0%
±400.0% 100.0 ƻ
P04.54±
P04.59
Reserved
P05 group²Input terminals
Function
code
Name Description Default
Modify
P05.00 HDI input type
0x0
0±0x11
Ones place: HDIA input type
0: HDIA is high
-speed pulse input
1: HDIA is digital input
0 Ƽ
P05.01
Function of S1
0: No function
1: Run forward
2: Run reversely
1
Ƽ
P05.02
Function of S2
4
Ƽ
P05.03
Function of S3
7
Ƽ
