Goodrive270 series VFD for fan and pump Function parameter list
-221-
P89 group²HVAC status viewing
Function
code
Name Description Default
Modify
P89.00
HVAC function
status
0: Disable
1: Enable
0 ƽ
P89.01
Variable-frequency
motor run SN
1
±8
The
SNs 1±8 correspond to motors A±F. For
fixed variable
-frequency motor control, the value
is always 1.
1 ƽ
P89.02
Multi-motor validity
status
0x00
±0xFF
Bit
0±Bit 7 correspond to motors A±H.
0: The corresponding motor is invalid and cannot
be put into service.
1: The corresponding motor is valid and can be
put into service.
0x00 ƽ
P89.03
Power-frequency
motor run status
0x00
±0xFF
Bit 0
±Bit 7 correspond to motors A±H.
0: The corresponding motor stops.
1: The corresponding motor is running.
0x00 ƽ
P89.04
SN of
power-frequency
motor to be polled
1
±8 2 ƽ
P89.05
Left time of
power-frequency
motor to be polled
0.00
±600.00h 0.00h ƽ
P89.06
SN of
variable-frequency
motor to be polled
1
±8 2 ƽ
P89.07
Left time of
variable-frequency
motor to be polled
0.00
±600.00h 0.00h ƽ
P89.08 PID1 status
Bit 0: Stopped
Bit 1: Paused
Bit 2: Integral paused
Bit 3: Deadzone
0 ƽ
P89.09
Present reference
value of PID1
-
100.0±100.0% 0.0% ƽ
P89.10
PID1 feedback value
-100.0±100.0%
0.0%
ƽ
P89.11
PID1 deviation input
-100.0±100.0%
0.0%
ƽ
