INVT GD270-090-4 - P26 Group I;O Card Output Functions

Goodrive270 series VFD for fan and pump Function parameter list
-217-
Function
code
Name Description Default
Modify
P25.27
setting range: -300.0%±300.0%
P25.28
setting range: 0.000s±10.000s
P25.29
setting range: 0.00V±P25.31
P25.30
setting range: -300.0%±300.0%
P25.31
setting range: P25.29±10.00V
P25.32
setting range: -300.0%±300.0%
P25.33
setting range: 0.000s±10.000s
P25.34
HDI3 high-speed
pulse input function
selection
0: Frequency setting
1:
Counting
0 Ƽ
P25.35
HDI3 lower limit
frequency
0.000 kHz
±P25.37
0.000
kHz
ƻ
P25.36
Corresponding
setting of HDI3 lower
limit frequency
-
300.0%±300.0% 0.0% ƻ
P25.37
HDI3 upper limit
frequency
P25.35
±50.000kHz
50.000
kHz
ƻ
P25.38
Corresponding
setting of HDI3
upper limit frequency
-
300.0%±300.0% 100.0% ƻ
P25.39
HDI3 frequency
input filter time
0.000s
±10.000s 0.030s ƻ
P25.40 AI3 input signal type
Range: 0
±1
0: Voltage
1: Current
0 ƻ
P25.41 AI4 input signal type
Range: 0
±1
0: Voltage
1: Current
0 ƻ
P25.42±
P25.45
Reserved
P26 group²I/O card output functions
Function
code
Name Description Default
Modify
P26.00 HDO2 output type
0: Open collector high
-speed pulse output
2: Open collector output
0 Ƽ
P26.01
HDO2 output
Same as the description for P06.01
0
ƻ
