INVT GD270-090-4 User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-161-
Function
code
Name Description Default
Modify
P05.41
HDIA upper limit
frequency
P05.39
±50.000kHz
50.000
kHz
ƻ
P05.42
Corresponding
setting of HDIA
upper limit frequency
-
300.0%±300.0% 100.0% ƻ
P05.43
HDIA frequency
input filter time
0.000s
±10.000s 0.030s ƻ
P05.44±
P05.49
Reserved
P05.50 AI1 input signal type
0: Voltage
1: Current
Note: If the input type is current, the AI
-
I short
cap on the control board needs to be shorted.
0 Ƽ
P05.51
Reserved
P05.52
Reserved
P05.53
Keypad analog
lower limit
0.00V
±P05.54 0.00V ƻ
P05.54
Corresponding
setting of keypad
analog lower limit
-
300.0%±300.0% 0.0% ƻ
P05.55
Keypad analog
upper limit
P05.56
±10.00V 10.00V ƻ
P05.56
Corresponding
setting of keypad
analog upper limit
-
300.0%±300.0% 100.0% ƻ
P05.57
Keypad analog input
filter time
0.000s
±10.000s 0.030s ƻ
P06 group²Output terminals
Function
code
Name Description Default
Modify
P06.00
Reserved
Reserved
P06.01
Y1 output
0: Disable
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
0
ƻ
P06.02
Reserved
0
ƻ
P06.03
RO1 output
1
ƻ
P06.04 Reserved
