INVT GD270-090-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-108-
Function
code
Name Description Default
P09.08
PID control deviation
limit
0.0±100.0%
0.0%
P09.09 PID output upper limit
P09.10±100.0% (of max. frequency or voltage)
100.0%
P09.10 PID output lower limit
-100.0%±P09.09 (Max. frequency or voltage)
0.0%
P09.11
Feedback offline
detection value
0.0±100.0%
0.0%
P09.12
Feedback offline
detection time
0.0±3600.0s
1.0s
P09.13 PID control selection
0x0000±0x1111
Ones place:
0: Continue integral control after the frequency
reaches upper/lower limit
1: Stop integral control after the frequency
reaches upper/lower limit
Tens place:
0: Same as the main reference direction
1: Contrary to the main reference direction
Hundreds place:
0: Limit as per the max. frequency
1: Limit as per A frequency
Thousands place:
0: A+B frequency. ACC/DEC of main reference A
frequency source buffering is invalid.
1: A+B frequency. ACC/DEC of main reference A
frequency source buffering is valid. The ACC/DEC
is determined by P08.04 (ACC time 4).
0x0001
P09.14
Low frequency
proportional gain (Kp)
0.00±100.00 1.00
P09.15
ACC/DEC time of PID
command
0.0±1000.0s 0.0s
P09.16 PID output filter time 0.000±10.000s 0.000s
P09.17 Reserved
P09.18
Low frequency
integral time (Ti)
0.00±10.00s 0.90s
P09.19
Low frequency
differential time (Td)
0.00±10.00s 0.00s
