INVT GD270-090-4 User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-135-
Function
code
Name Description Default
Modify
P01.31
Hold time of
short-
circuit braking
for stop
stop (
P01.09), set P01.31 to a non-zero value to
enter short
-
circuit braking for stop, and then carry
out DC braking in the t
ime set by P01.12. (See
descriptions for
P01.09±P01.12.)
P01.29
setting range: 0.0±150.0% (VFD)
P01.30
setting range: 0.0±50.00s
P01.31 setting range: 0.0±50.00s
0.00s ƻ
P01.32
Pre-
exciting time for
jogging
0
±10.000s 0.300s ƻ
P01.33
Starting frequency of
braking for stop in
jogging
0
±P00.03 0.00Hz ƻ
P01.34
Sleep delay
0±3600.0s
0.0s
ƻ
P01.35
Speed tracking
method
Speed tracking method
0: From stop frequency
1: From low frequency
2: From max. frequency (P00.03)
0 ƻ
P01.36
Quick/slo
w selection
for speed tracking
1
±100 15 ƻ
P01.37
Speed tracking
current
30%
±200% (motor) 100% ƻ
P01.38
Demagnetization
time for speed
tracking
0.0
±10.0s
Model
depended
ƻ
P01.39
Advanced control for
speed tracking
0x000
±0x111
LED ones place: Current givi
ng mode in vector
control
0: 120% of current is given during startup, which
is switched to the given value based on P01.35
1: The current is given based on P01.35
LED ones place: PWM mode selection
0: 2PH modulation mode
1: Based on P08.40
LED hundreds pla
ce: Search direction for speed
tracking
0: Allow both forward and reverse search
1: Disallow reverse search
0x110 ƻ
