INVT GD270-090-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-64-
Function
code
Name Description Default
P00.00
Speed control
mode
0: Sensorless vector control (SVC) mode 0
1: Sensorless vector control (SVC) mode 1
2: Space voltage vector control mode
Note: Before using a vector control mode (0 or 1),
enable the VFD to perform motor parameter
autotuning first.
2
P03.32
Enabling torque
control
0: Disable
1: Enable
0
P03.11
Torque setting
source
0: Keypad (P03.12)
1: Keypad (P03.12)
2: AI1
3: AI2
4: AI3
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen/DeviceNet communication
9: Ethernet communication
10: Reserved
11: EtherCAT/PROFINET communication
12: Programmable expansion card
13±17: Reserved
18: Keypad (for small power models)
Note: For setting sources 2±6, 100%
corresponds to triple the motor rated current.
0
P03.12
Torque set
through keypad
-300.0%±300.0% (of the motor rated current) 50.0%
P03.13
Torque reference
filter time
0.000±10.000s 0.010s
P03.14
Setting source of
forward rotation
upper-limit
frequency in
torque control
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus communication
7: PROFIBUS/CANopen/DeviceNet communication
8: Ethernet communication
0
