INVT GD270-090-4 - Page 85

Goodrive270 series VFD for fan and pump Basic operation guidelines
-75-
Function
code
Name Description Default
P01.23
Start delay 0.0±60.0s 0.0s
P01.24
Stop speed delay
0.0±100.0s
0.0s
P01.25
Open-loop 0Hz output
selection
0: Output without voltage
1: Output with voltage
2: Output with the DC braking current for
stop
0
P01.26
DEC time for emergency
stop
0.0±60.0s 2.0s
P01.27
Time of starting segment of
DEC S curve
0.0±50.0s 0.1s
P01.28
Time of ending segment of
DEC S curve
0.0±50.0s 0.1s
P01.29
Short-circuit braking current 0.0±150.0% (of the VFD rated current) 0.0%
P01.30
Hold time of short-circuit
braking for start
0.00±50.00s 0.00s
P01.31
Hold time of short-circuit
braking for stop
0.00±50.00s 0.00s
P01.32
Pre-exciting time for jogging
0±10.000s
0.300s
P01.33
Starting frequency of braking
for stop in jogging
0±P00.03 0.00Hz
P01.34
Sleep delay
0±3600.0s
0.0s
P05.01±
P05.06
Digital input function
selection
1: Run forward
2: Run reversely
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
30: Disable ACC/DEC
P08.00 ACC time 2 0.0±3600.0s
Model
depended
P08.01 DEC time 2 0.0±3600.0s
Model
depended
P08.02 ACC time 3 0.0±3600.0s
Model
depended
P08.03 DEC time 3 0.0±3600.0s
Model
depended
