INVT Goodrive 200A User Manual

Goodrive200A inverters
Communication protocol
128
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
Bit3: =0:asynchronous motor
=1:synchronous motor
Bit4:=0:pre-alarm without overload
=1:overload pre-alarm
Bit5~ Bit6:=00:keypad control
=01:terminal control
=10:commuincation control
Fault code of the
inverter
2102H See the fault type instruction R
Identifying code
of the inverter
2103H GD200A -----0x010C R
Operation
frequency
3000H Range: 0.00Hz~P00.03 R
Setting
frequency
3001H Range: 0.00Hz~P00.03 R
Bus voltage 3002H Range: 0~1200V R
Output voltage
3003H Range: 0~1200V R
Output current
3004H Range: 0.0~5000.0A R
O
peration speed
3005H Range: 0~65535RPM
R
Output power
3006H Range: -300.0~300.0%
R
Output torque
3007H Range: 0~65535RPM
R
Close loop
setting
3008H Range: -100.0%~100.0% R
Close loop
feedback
3009H Range: -100.0%~100.0% R
Input IO state
300AH Range: 0000~00FF
R
Output IO state
300BH Range: 0000~00FF
R
AI 1 300CH Range: 0.00~10.00V
R
AI 2 300DH Range: 0.00~10.00V
R
AI 3 300EH Range: 0.00~10.00V
R
AI 4 300FH Reserved
R
Read high speed
pulse 1 input
3010H Range: 0.00~50.00kHz R
Read high speed
pulse 2 input
3011H Reserved R
Read current
step of the
multi-step speed
3012H Range: 0~15 R
External length
3013H Range: 0~65535
R
External 3014H Range: 0~65535
R
