For 3-phase 200 V drives, the maximum altitude is 3000m above sea level. In altitudes
2000…3000 m, the derating is 1% for every 100 m.
A.2.2.3 Carrier frequency derating
For Goodrive200A series inverters, different power level corresponds to different carrier
frequency range. The rated power of the inverter is based on the factory carrier frequency,
so if it is above the factory value, the inverter needs to derate 20% for every additional 1 kHz
carrier frequency.
A.3 Electric power network specification
Voltage
AC 3PH 220(-15%)~240(+10%)
AC 3PH 380(-15%)~440(+10%)
AC 3PH 520(-15%)~690(+10%)
Short-circuit
capacity
Maximum allowed prospective short-circuit current at the input
power connection as defined in IEC 60439-1 is 100 kA. The drive is
suitable for use in a circuit capable of delivering not more than 100
kA at the drive maximum rated voltage.
Frequency 50/60 Hz ± 5%, maximum rate of change 20%/s
A.4 Motor connection data
Motor type Asynchronous inductance motor
Voltage 0 to U1, 3-phase symmetrical, Umax at the field weakening point
Short-circuit
protection
The motor output is short-circuit proof by IEC 61800-5-1
Frequency 0...400 Hz
Frequency
resolution
0.01 Hz
Current Refer to Ratings
Power limit 1.5 · PN
Field weakening
point
10...400 Hz
Carrier frequency
4, 8, 12 or 15 kHz
A.4.1 EMC compatibility and motor cable length
To comply with the European EMC Directive (standard IEC/EN 61800-3), use the following
maximum motor cable lengths for 4 kHz switching frequency.
All frame sizes Maximum motor cable length, 4 kHz
Second environment (category C3) 30
first environment (category C2) 30
Maximum motor cable length is determined by the drive’s operational factors. Contact your
local INVT representative for the exact maximum lengths when using external EMC filters.
A.5 Applicable standards
The inverter complies with the following standards:
