Goodrive200A inverters Fault tracking
104
Fault Tracking 8
8.1 What this chapter contains
This chapter describes how to reset faults and view fault history. It also lists all alarm and
fault messages including the possible cause and corrective actions.
Only qualified electricians are allowed to maintain the inverter. Read the
safety instructions in chapter Safety precautions before working on the
inverter.
8.2 Alarm and fault indications
Fault is indicated by LEDs. See Operation Procedure. When TRIP light is on, an alarm or
fault message on the panel display indicates abnormal inverter state. Using the information
reference in this chapter, most alarm and fault cause can be identified and corrected. If not,
contact with the INVT office.
8.3 How to reset
The inverter can be reset by pressing the keypad key STOP/RST, through digital input, or by
switching the power light. When the fault has been removed, the motor can be restarted.
8.4 Fault history
Function codes P07.27~P07.32 store 6 recent faults. Function codes P07.33~P07.40,
P07.41~P7.48 and P07.49~P07.56 show drive operation data when the latest 3 faults
occurs.
8.5 Fault instruction and solution
Do as the following after the inverter fault:
1. Check to ensure there is nothing wrong with the keypad. If not, please contact with the
local INVT office.
2. If there is nothing wrong, please check P07 and ensure the corresponding recorded fault
parameters to confirm the real state when the current fault occurs by all parameters.
3. See the following table for detailed solution and check the corresponding abnormal state.
4. Eliminate the fault and ask for relative help.
5. Check to eliminate the fault and carry out fault reset to run the inverter.
F
ault code
Fault type Possible cause What to do
OUt1 IGBT Ph-U fault
The acceleration is too
fast
IGBT module fault
Misaction caused by
interference
The connection of the
driving wires is not good,
Grounding is not properly
Increase Acc time
Change the power unit
Check the driving wires
Inspect external
equipment and eliminate
interference
OUt2 IGBT Ph-V fault
OUt3 IGBT Ph-W fault
