INVT Goodrive 200A User Manual

Goodrive200A inverters
Appendix C
147
connecting to the drive.
Note: Check the insulation of the input power cables according to local regulations
before connecting the cables.
Note:
1. It is appropriate to use the recommended cable size under 40℃ and rated current. The
wiring distance should be no more than 100m.
2. Terminals P1, (+), PB and (-) connects the DC reactor options and parts.
The inverter
Recommended cable size(mm
2
) Screw
R,S,T
U,V,W
PE P1(+)
PB(+)(-)
Terminal
screw
size
Tightening
torque
(Nm)
GD200A -0R7G-4 2.5 2.5 2.5 2.5 M4 1.2~1.5
GD200A -1R5G-4 2.5 2.5 2.5 2.5 M4 1.2~1.5
GD200A -2R2G-4 2.5 2.5 2.5 2.5 M4 1.2~1.5
GD200A
-004G/5R5P-4
2.5 2.5 2.5 2.5 M4 1.2~1.5
GD200A
-5R5G/7R5P-4
4 4 2.5 2.5 M5 2~2.5
GD200A -7R5G/011P-4
6 6 4 2.5 M5 2~2.5
GD200A -011G/015P-4
10 10 6 4 M5 2~2.5
GD200A -015G/018P-4
10 10 10 4 M5 2~2.5
GD200A -018G/022P-4
16 16 10 6 M6 4~6
GD200A -022G/030P-4
25 16 16 10 M6 4~6
GD200A -030G/037P-4
25 16 16 10 M8 9~11
GD200A -037G/045P-4
35 16 25 16 M8 9~11
GD200A -045G/055P-4
50 25 35 25 M8 9~11
GD200A -055G/075P-4
70 35 50 25 M10 18~23
GD200A -075G/090P-4
95 50 70 35 M10 18~23
GD200A -090G/110P-4
120 70 95 35 M10 18~23
GD200A -110G/132P-4
150 70 120 70 M12 31~40
GD200A -132G/160P-4
185 95 150 95 M12 31~40
GD200A -160G/185P-4
240 95 185 50 M12 31~40
GD200A -185G/200P-4
120*2P
150 95*2P
50 M12 31~40
GD200A -200G/220P-4
120*2P
150 95*2P
50 M12 31~40
GD200A -220G/250P-4
150*2P
150 95*2P
50 M12 31~40
GD200A -250G/280P-4
150*2P
150 120*2P
95 M12 31~40
GD200A -280G/315P-4
185*2P
185 120*2P
95 M12 31~40
GD200A -315G/350P-4
185*2P
185 120*2P
95 M12 31~40
GD200A -350G/400P-4
95*4P
95*2P
150*2P
120 M12 31~40
GD200A -400G-4 95*4P
95*2P
150*2P
120 M12 31~40
GD200A -500G-4 120*4P
95*2P
95*4P
120 M12 31~40
