INVT Goodrive 200A User Manual

Goodrive200A inverters Function parameters
31
Function
code
Name Detailed instruction of parameters
Default
value
Modify
100.0% of the analog input setting corresponds
to the maximum frequency (function code
P00.03) in forward direction and -100.0%
corresponds to the maximum frequency in
reverse direction (function code P00.03)
4:High-speed pulse HDI setting
The frequency is set by high-speed pulse
terminals. Goodrive200A series inverters provide
1 channel high speed pulse input as the standard
configuration. The pulse frequency range is
0.00~50.00kHz.
100.0% of the high speed pulse input setting
corresponds to the maximum frequency in
forward direction (P00.03) and -100.0%
corresponds to the maximum frequency in
reverse direction (P00.03).
Note: The pulse setting can only be input by
multi-function terminals HDI. Set P05.00 (HDI
input selection) to high speed pulse input, and
set P05.49 (HDI high speed pulse input function
selection) to frequency setting input.
5:Simple PLC program setting
The inverter runs at simple PLC program mode
when P00.06=5 or P00.07=5. Set P10 (simple
PLC and multi-step speed control) to select the
running frequency, running direction, ACC/DEC
time and the keeping time of corresponding step.
See the function description of P10 for detailed
information.
6: Multi-step speed running setting
The inverter runs at multi-step speed mode when
P00.06=6 or P00.07=6. Set P05 to select the
current running step, and set P10 to select the
current running frequency.
The multi-step speed has the priority when
P00.06 or P00.07 does not equal to 6, but the
setting step can only be the 1~15 step. The
setting step is 0~15 if P00.06 or P00.07 equals to
6.
7: PID control setting
The running mode of the inverter is process PID
