Goodrive200A inverters Function parameters
76
Function
code
Name Detailed instruction of parameters
Default
value
Modify
P08.51
Input power
factor of the
inverter
This function code is used to adjust the displayed
current of the AC input side.
Setting range:0.00~1.00
0.56 ○
P09 Group PID control
P09.00
PID
reference
source
When the frequency command selection
(P00.06, P00. 07) is 7 or the voltage setting
channel selection (P04.27) is 6, the running
mode of the inverter is procedure PID controlled.
The parameter determines the target reference
channel during the PID procures.
0:Keypad digital reference(P09.01)
1:Analog channel AI1 reference (The inverter
(≤15kW) can be set by the analog potentiometer
on the keypad and AI1 setting is not available for
the device which is 18.5kW or higer than 18.5kW)
2:Analog channel AI2 reference
3:Analog channel AI3 set
4:High speed pulse HDI set
5:Multi-step speed set
6:MODBUS communication set
The setting target of procedure PID is a relative
one, 100% of the setting equals to 100% of the
response of the controlled system.
The system is calculated according to the relative
value (0~100.0%).
Note:
Multi-step speed reference, it is realized
by
setting P10 group parameters.
0 ○
P09.01
Keypad PID
preset
When P09.00=0, set the parameter whose basic
value is the feedback value of the system.
The setting range:-100.0%~100.0%
0.0% ○
P09.02
PID
feedback
source
Select the PID channel by the parameter.
0:Analog channel AI1 feedback (The inverter(≤
15kW) can be set by the analog potentiometer on
the keypad and AI1 setting is not available for the
device which is 18.5kW or higer than 18.5 kW)
1:Analog channel AI2 feedback
2:Analog channel AI3 feedback
3:High speed HDI feedback
4:MODBUS communication feedback
Note: The reference channel and the feedback
0 ○
