Goodrive18 series two-in-one VFD Installing
-12-
-40°C – +70°C. The air temperature change rate is less than 1°C/min.
The installation site must be:
Away from electromagnetic radiation sources.
Away from oil mist, corrosive gases and combustible gases.
Protective from foreign materials such as metal powder, dust, oil, and
water so that the foreign materials will not fall into the VFD. (Do not
install the VFD on inflammables such as wood.)
Away from radioactive substances and combustible objects.
Away from harmful gases and liquids.
With a low salt content density.
No direct sunlight.
When the altitude is higher than 1000m but lower than 3000m, derate by
1% for every increase of 100m.
When the altitude is higher than 2000m, configure an isolation
transformer at the VFD input end.
When the altitude is higher than 3000m but lower than 5000m, consult
INVT for technical issues.
It is not recommended that the VFD be used at the altitude higher than
5000m.
The max. vibration amplitude cannot exceed 5.8m/s
2
(0.6g).
Install the VFD vertically to ensure good heat dissipation effect.
Note:
The VFD needs to be installed in a clean and well-ventilated environment based on the IP
rating of the VFD housing.
The cooling air must be clean enough and free from corrosive gases and conductive dust.
3.1.2 Installation direction
The VFD can be installed on the wall or in a cabinet.
The VFD must be installed vertically. Check the installation position according to following
requirements. For details about outline dimensions, see Appendix B "Dimensional drawing".
3.1.3 Installation method
Goodrive18 series 2-in-1 VFD supports wall mounting.
