Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-28-
5 Function parameters and function terminal reuse
5.1 Function parameter list
The function parameters of Goodrive18 series two-in-one VFD are divided into 30 groups
(P00–P29) by function, and each function group includes several function codes (each
function code identifies a function parameter). A three-level menu style is applied to function
codes. For example, "P08.08" indicates the 8th function code in the P00 group. The P29 group
indicates factory function parameters, which are user inaccessible.
The function group numbers correspond to the level-1 menus, the function codes correspond
to the level-2 menus, and the function parameters correspond to the level-3 menus.
1. The content of the function code table is as follows:
Column 1 "Function code ": Code of the function group and parameter
Column 2 "Name": Full name of the function parameter
Column 3 "Description": Detailed description of the function parameter
Column 4 " Default value": Initial value set in factory
Column 5 " Modify": Whether the function parameter can be modified, and conditions for the
modification
"○" indicates that the value of the parameter can be modified when the VFD is in stopped or
running state.
"◎" indicates that the value of the parameter cannot be modified when the VFD is in running
state.
"●" indicates that the value of the parameter is detected and recorded, and cannot be
modified.
(The VFD automatically checks and constrains the modification of parameters, which helps
prevent incorrect modifications.)
2. The parameters adopt the decimal system (DEC). If the hexadecimal system is
adopted, all bits are mutually independent on data during parameter editing, and the setting
ranges at some bits can be hexadecimal (0–F).
3. "Default value" indicates the factory setting of the function parameter. If the value of the
parameter is detected or recorded, the value cannot be restored to the factory setting.
4. To better protect parameters, the VFD provides the password protection function. After
a password is set (that is, P07.00 is set to a non-zero value), "0.0.0.0.0" is displayed when you
press the PRG/ESC key to enter the function code editing interface. You need to enter the
correct user password to enter the interface. For the factory parameters, you need to enter the
