Goodrive18 series two-in-one VFD Communication
-127-
• Besides, EEPROM is stocked frequently, which may shorten the usage time of EEPROM.
For users, some functions are not necessary to be stocked on the communication mode.
The needs can be met on by changing the value in RAM. Changing the MSB of the
function code form 0 to 1 can also realize the function. For example, the function code
P00.07 is not stocked into EEPROM. Only by changing the value in RAM can set the
address to 8007H. This address can only be used in writing RAM other than reading. If it is
used to read, it is an invalid address.
7.4.2 Address description of other function codes
In addition to modifying the parameters of the VFD, the master can also control the VFD, such
as starting and stopping the VFD, and monitoring the running status of the VFD. The following
table lists other function parameters.
Function
Address
Description
R/W
Communication-based
control command
2000H
0001H: forward running
R/W
0002H: reverse running
0003H: forward jogging
0004H: reverse jogging
0005H: stop
0006H: coast to stop (emergency stop)
0007H: fault reset
0008H: jogging stop
Communication-based
setting address
2001H
Communication-set frequency (0–Fmax, unit:
0.01Hz)
R/W
2002H
PID reference, range (0–1000, 1000
corresponds to 100.0%)
2003H
PID feedback, range (0–1000, 1000
corresponds to 100.0%)
R/W
2004H
Torque setting (-3000–3000, 1000
corresponds to the 100.0% of the rated current
of the motor)
R/W
2005H
The upper limit frequency setting during
R/W
