INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Communication
-128-
Function
Address
Description
R/W
forward rotation (0–Fmax (unit: 0.01Hz))
2006H
The upper limit frequency setting during
reverse rotation (0–Fmax (unit: 0.01Hz))
R/W
2007H
The upper limit torque of electromotion torque
(0–3000, 1000 corresponds to the 100.0% of
the rated current of the motor)
R/W
2008H
The upper limit torque of braking torque (0–
3000, 1000 corresponds to the 100.0% of the
rated current of the motor)
R/W
2009H
Special control command word
Bit0–1: =00: motor 1 =01: motor 2
=10: motor 3 =11: motor 4
Bit2: =1 torque control prohibit
=0: torque control prohibit invalid
Bit3: =1 power consumption clear
=0: no power consumption clear
Bit4: =1 pre-exciting =0: pre-exciting
prohibition
Bit5: =1 DC braking =0: DC braking
prohibition
R/W
200AH
Virtual input terminal command, range: 0x000–
0x1FF
R/W
200BH
Virtual output terminal command, range:
0x00–0x0F
R/W
200CH
Voltage setting value (special for V/F
separation)
(0–1000, 1000 corresponds to the 100.0% of
the rated voltage of the motor)
R/W
