INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Communication
-129-
Function
Address
Description
R/W
200DH
AO output setting 1
(-1000–1000, 1000 corresponds to 100.0%)
R/W
200EH
AO output setting 2
(-1000–1000, 1000 corresponds to 100.0%)
R/W
SW 1 of the VFD
2100H
0001H: forward running
R
0002H: reverse running
0003H: stop
0004H: fault
0005H: POFF state
0006H: pre-exciting state
SW 1 of the VFD
2101H
Bit0: =0: not ready to run =1: ready to run
Bi1–2: =00: motor 1 =01: motor 2
=10: Reserved =11: Reserved
Bit3: =0: AM =1: SM
Bit4: =0: pre-alarm without overload =1:
overload pre-alarm
Bit5– Bit6: =00: keypad control
=01: terminal control
=10: communication control
R
Fault code of the VFD
2102H
See the fault type description.
R
Identifying code of the
VFD
2103H
GD18-----0x0106
R
Operation frequency
3000H
0–Fmax, unit: 0.01Hz
Compatible with
R
