INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Communication
-130-
Function
Address
Description
R/W
Set frequency
3001H
0–Fmax, unit: 0.01Hz
the
communication
addresses of GD,
CHF100A, and
CHV100 series
R
Bus voltage
3002H
0.0–2000.0V, unit: 0.1V
R
Output voltage
3003H
0–1200V, unit: 1V
R
Output current
3004H
0.0–3000.0A, unit: 0.1A
R
Running speed
3005H
0–65535, unit: 1RPM
R
Output power
3006H
-300.0–300.0%, unit:
0.1%)
R
Output torque
3007H
-250.0–250.0%, unit: 0.1%
R
PID setting
3008H
-100.0–100.0%, unit: 0.1%
R
PID feedback
3009H
-100.0–100.0%, unit: 0.1%
R
Input status
300AH
000–1FF
R
Output status
300BH
000–1FF
R
AI 1
300CH
0.00–10.00V, unit: 0.01V
R
AI 2
300DH
0.00–10.00V, unit: 0.01V
R
AI 3
300EH
-10.00–10.00V, unit:
0.01V
R
AI 4
300FH
Reserved
R
Reading high speed
pulse 1 input
3010H
0.00–50.00kHz, unit:
0.01Hz
R
Reading high speed
pulse 2 input
3011H
Reserved
R
PLC and current step
of multi-step speed
3012H
0–15
R
External length
3013H
0–65535
R
External counting
value
3014H
0–65535
R
Torque setting
3015H
-300.0–300.0%, unit:
0.1%)
R
VFD code
3016H
R
Fault code
5000H
R
The Read/Write (R/W) characteristics indicate whether a function code can be read and
written. For example, "Communication-based control command" can be written, and therefore
the command code 06H is used to control the VFD. "R" indicates that a function code is read
