INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Product overview
-6-
rotational direction is correct. If not, change the rotation direction by swapping any two
phase wires of the motor.
4. Set all control parameters and then operate.
2.2 Product specifications
Function
Specifications
Power input
Rated input
voltage (V)
For the -4 type: 3PH 380V(-15%)–440V(+10%)
Rated input
current (A)
See "Product ratings".
Rated
frequency
50Hz or 60Hz, allowable range: 47–63Hz
Power output
Rated motor
capacity (kW)
See "Product ratings".
Rated output
(kVA)
See "Product ratings".
Rated current
(A)
See "Product ratings".
Rated output
voltage (V)
Equal to the input voltage, with the deviation less than 5%
Rated output
frequency
(Hz)
0–400Hz
Technical
control
performance
Control mode
V/F control and sensorless vector control (SVC)
Motor type
Asynchronous motor (AM)
Speed ratio
1:100
Speed
control
accuracy
±0.2% (SVC)
Speed
fluctuation
± 0.3% (SVC)
Torque
response
<20ms (SVC)
Torque
control
accuracy
10% (SVC)
Starting
torque
0.5Hz 150% (SVC)
