INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Product overview
-9-
Field
No.
Description
Example
Abbreviation of
product series
①
Abbreviation of
product series
GD18: short for Goodrive18
Rated power
②
Power range + load
type
7R5: 7.5kW
Voltage class
③
Voltage class
4: AC 3PH 380V(-15%)–440V(+10%)
Structure
④
Number of devices
in the combination
2: Two in one, two inverting outputs
2.5 Product ratings
VFD model
Voltage
class
Output power
(kW)
Input current
(A)
Output current
(A)
GD18-0R7-4-2
3PH 380V
0.75/0.75
7
2.5/2.5
GD18-1R5-4-2
1.5/1.5
10
4.2/4.2
GD18-2R2-4-2
2.2/2.2
12
5.5/5.5
GD18-004-4-2
4/4
25
9.5/9.5
GD18-5R5-4-2
5.5/5.5
32
14/14
GD18-7R5-4-2
7.5/7.5
40
18.5/18.5
2.6 Structural diagram
The VFD structure is shown in the following figure (using the 7.5kW model as an example):
