INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Product overview
-7-
Function
Specifications
Overload
capacity
150% for 1min, 180% for 10s, 200% for 1s
Running
control
performance
Frequency
setting
method
Settings can be implemented through digital, analog, pulse
frequency, multi-step speed running, simple PLC, PID,
MODBUS communication, and so on.
Settings can be combined and the setting channels can be
switched.
Automatic
voltage
regulation
The output voltage can be kept constant although the grid
voltage changes.
Fault
protection
All-round protection functions, such as protection against
overcurrent, overvoltage, undervoltage, overheat, phase loss,
and overload.
External
interface
Analog input
AI2: 0–10V/0–20mA Whether the output type is voltage or
current can be selected through P05.49.
AI3: -10V–10V
AI2/AI3 min. resolution: 10mV/20mV
Analog
output
1. Output range: AO1/AO2, 0–10V/0–20mA
2. Whether the output type is voltage or current can be selected
through the control board jumper.
3. Full range deviation: ±1%, 25°C
Digital input
Eight common inputs, max. frequency 1kHz
Relay output
Two programmable relay outputs:
RO1A is NO, RO1B is NC, and RO1C is the common terminal.
RO2A is NO, RO2B is NC, and RO2C is the common terminal.
Contact capacity: 3A/AC250V
Other
Installation
method
Wall mounting
Brake unit
None
EMI filter
You can choose to use the external filter, meeting IEC61800-3
C3/C2 requirements.
Temperature
of operating
environment
-10–50°C. If the temperature exceeds 40°C, derate 1% for
every increase of 1°C.

INVT Goodrive18 Series Specifications

General

Brand	INVT
Model	Goodrive18 Series
Category	Industrial Electrical
Language	English
