INVT XD Series User Manual

Single Phase Hybrid Inverter Installation
9
Fig. 4.1 Deliverables for Hybrid Inverter XD3~6KTL
Table 4-1 List of Deliverables for Hybrid Inverter
No.
Name
Quantity
1
Inverter
1
2
Mounting bracket
1
3
Quick-connect AC terminal and hexagon
screwdriver
2
4
Wiring terminal
1
5
DC connectors (pair)
2
6
Accompanying documents (set)
1
7
M6×50 stainless-steel expansion bolt
6
8
M6 combination bolts
9
9
M4 combination screws
6
10
M6 nut
6
11
M6 flat washer
6
12
CT
1
Please check the above items carefully, and contact your dealer immediately if you have any questions.
4.2 Preparations for Installation
4.2.1 Installation Tools
Table 4-2 List of Installation Tools
No.
Installation Tool
Description
1
Marker
Mark mounting holes
2
Electric drill
Drill holes in the mounting bracket or wall
3
Hammer
Drive expansion bolts
4
Adjustable wrench
Fix the mounting bracket
5
Screwdriver
Fix the inverter and tighten the junction box
6
Slotted screwdriver or Phillips
screwdriver
For AC wiring use
7
Megger
Measure the insulation performance and resistance
to ground
8
Multimeter
To test circuits and measure AC/DC voltage
9
Electric soldering iron
To weld the communication cable
