INVT XD Series User Manual

Single Phase Hybrid Inverter Troubleshooting
64
No.
Fault Type
Fault
Code
Fault Description
Actions
31-10
Oscillation of grid voltage
14
AC
frequency
error
33-01
One-level under-
frequency of AC power
1. If the fault occurs occasionally, it may
be caused by momentary abnormality of the
power grid. The inverter will resume normal
operation when the power grid gets back to
normal.
2. If the fault occurs frequently, check
whether the power grid is connected properly.
33-02
One level over-frequency
of AC power
33-03
Two-level under-
frequency of AC power
33-04
Two-level over-frequency
of AC power
33-05
Startup under-frequency
of AC power
33-06
Startup over-frequency of
AC power
15
Remote
shutdown
37-01
Remote shutdown
instruction
Check whether any one is trying to shut down
the inverter remotely.
16
AFCI error
38-01
Failure of PV string 1
Please turn off the inverter and open the input
and output switches, and turn on the inverter
again 5 minutes later. If the fault still exists,
contact your dealer.
38-02
Failure of PV string 2
17
Power-on
self-test
error of
AFCI
39-01
Power-on self-test error of
PV string 1
Please turn off the inverter and open the input
and output switches, and turn on the inverter
again 5 minutes later. If the fault still exists,
contact your dealer.
39-02
Power-on self-test error of
PV string 2
18
AutoTest
failure
41-01
AutoTest failure
Please turn off the inverter and open the input
and output switches, and turn on the inverter
again 5 minutes later. If the fault still exists,
contact your dealer.
19
N-PE fault
42-01
N-PE voltage error
Check whether the AC wires are connected
properly and reliably to the inverter.
20
Power-on
self-test
error of
leakage
current
43-01
Leakage current sensor
failure
Please turn off the inverter and open the input
and output switches, and turn on the inverter
again 5 minutes later. If the fault still exists,
contact your dealer.
21
PV string
detection
error
44-01
PV string failure
Please turn off the inverter and open the input
and output switches, and turn on the inverter
again 5 minutes later. If the fault still exists,
contact your dealer.
22
Auxiliary
45-01
Auxiliary power failure
Please turn off the inverter and open the input
