INVT XD Series User Manual

Single Phase Hybrid Inverter Product Specifications
67
XD3KTL
XD3K6TL
XD4KTL
XD4K6TL
XD5KTL
XD6KTL
Battery Parameters
Battery type
Lithium battery or lead-acid battery
Battery voltage (V)
40-60
40-60
40-60
40-60
40-60
40-60
Maximum charge and
discharge current (A)
100
100
100
100
100
100
Communication mode
CAN
CAN
CAN
CAN
CAN
CAN
DC input
Maximum input power (W)
4500
5400
6000
6900
7500
9000
Maximum input voltage (V)
600
600
600
600
600
600
Start-up voltage (V)
100
100
100
100
100
100
Rated voltage (V)
240
240
270
300
330
360
MPPT voltage (V)
100-550
100-550
100-550
100-550
100-550
100-550
MPPT channels
2
2
2
2
2
2
Maximum input current (A)
16
16
16
16
16
16
Maximum input short-circuit
current (A)
20
20
20
20
20
20
AC output
Rated output power (VA)
3000
3680
4000
4600
5000
6000
Maximum output power (VA)
3300
3680
4400
4600
5500
6000
Maximum output current (A)
15
16
20
20.9
22.7
30
Rated voltage (V)
230
230
230
230
230
230
Rated frequency (Hz)
50
50
50
50
50
50
Total harmonic distortion of
current (@ rated power)
＜3%
＜3%
＜3%
＜3%
＜3%
＜3%
Power factor
0.8 lead ~ 0.8 lag
EPS output
Maximum output power (VA)
3000
3680
4000
4600
5000
6000
Maximum output current (A)
15
16
20
20.9
22.7
30
Peak output power, time (KW,
s)
4.5,10
5.4,10
6,10
6.9,10
7.5,10
9,10
Rated output voltage,
frequency (V, Hz)
230, 50
230, 50
230, 50
230, 50
230, 50
230, 50
THDv (@ rated power)
＜3%
＜3%
＜3%
＜3%
＜3%
＜3%
Switching time (ms)
＜10
＜10
＜10
＜10
＜10
＜10
Efficiency
Maximum efficiency
＞97.5%
＞97.5%
＞97.5%
＞97.5%
＞97.5%
＞97.5%
European efficiency
＞97.2%
＞97.2%
＞97.2%
＞97.2%
＞97.2%
＞97.2%
