Test mode 7
The test mode is set up to help finding technical failures and is rather made for specialists.
To enter “test mode”, you have to :
- Put in front the key switch in position “PROG”.
Press “+” or “-” button until the display indicates" tESt ".
Give a number from 1 to 7 to choose one of the below mentioned test functions.
To leave test mode : press the “STOP” button
Test 1 : check the 8 inlets
Here it is indicated if the inlet contacts are opened (o) or closed (c).
To check the next inlet : press “ENTER”.
To check the previous inlet : press “NO”.
To stop this test, press “STOP”.
inP.tHEr.o : heat motor security.
inP.hEY .o : key switch
inP.LOCh.o : doorlock S2
inP.door.o : doorlock S1
inP.tiLt.c : tilt switch
inP.SEnS.c : sensor for rpm
inP.tiHo.o: not applicable
inP.bS .o : not applicable
Example :
" t1.tHEr.o " : heat motor security open
" t1.tHEr.c " : heat motor security closed
Test 2 : check the rpm
Step by step the basic speeds of the machine are executed.
Press “ENTER” each time to go to the next step.
P000u0.00
P000u0.00 the door is locked
Lo((u0.41 the drum turns left at wash speed. The target rpm are indicated on the right, whereas the
control signal (XX) is indicated on the left.
P000u0.00 Pause
ro((u0.41 the drum turns right at wash speed. The target rpm are indicated on the right, whereas the
control signal (XX) is indicated on the left.
do((u0.84 the drum turns right at distribution speed. The target rpm are indicated on the right,
whereas the control signal is indicated on the left.
lo((u5.00 the drum turns right at low spin. The target rpm are indicated on the right, whereas the
control signal (XX) is indicated on the left.
Ho((u1.00 the drum turns right at high spin. The target rpm are indicated on the right, whereas the
control signal (XX) is indicated on the left.
Om uit de test mode te gaan: druk op de " STOP " toets.
