Test mode 7
Test 3 : coin meters
Here we check the value and the operating of the coin meters.
The display shows : “ ”.
Each time when a coin is inserted, the value of this coin is counted and the new value is shown.
By pressing the 0 button, this value is brought back to 0.
To stop this test, press the “STOP” button.
Test 4 : Calibrate the water level sensor
In this program, you can program the 0-level, maximum level and the number of divisions.
Wait to start the program until the water is out of the tub.
The display indicates “t4.LEV ((.(”.
By pressing “0”, the 0-level is calibrated.
Then press the “START” button.
Now the valve will be closed and water will be taken. The display shows the respective water level.
When the value does not longer increase on the display, this means that the highest level is achieved.
Press the “STOP” button now. Through this, the water inlet is stopped.
Then press “1”. Through this, the highest level is calibrated.
Now program at “t4.LEV ((.(” the number of divisions (maximum 99) and press “ENTER”.
To stop the test , press the “STOP” button again.
Test 5 : check the temperature sensor
The display shows " t5.((.( ". " XX.X " means the respective temperature in the tub.
To stop this test, press the “STOP” button.
Test 6 : check the 24 outlets.
Here you can activate by turns the outlet contacts.
To check the next outlet, press “ENTER”.
By pressing “0” or “1”, the contact is opened or closed and the last display shows respectively “o” (open) or “c”
To check the previous outlet, press “NO”.
To stop this test, press the “STOP” button.
Out.door.o: door lock
Out.rd1 .o: recycling exhaust valve 1
Out.rd2 .o: recycling exhaust valve 2
Out.rp .o: circulation pump
Out.ir3 .o: recycling inlet valve 3
Out.ir2 .o: recycling inlet valve 2
Out.heat.o: heating
Out.irI .o: recycling inlet valve 1
Out.i9 .o: inlet valve 9
Out.hot .o: warm water inlet valve 8
Out.col .o: cold water inlet valve 7
Out.i6 .o: inlet valve 6
Out.i5 .o: inlet valve 5
Out.i4 .o: inlet valve 4
Out.i3 .o: inlet valve 3
Out.i2 .o: inlet valve 2
Out.i1 .o: inlet valve 1
Out.SO1 .o: soap pump 1
Out.S12 .o: soap pump 12
Out.drA1.o: exhaust valve 1
Out.drA2.o: exhaust valve 2
