TXG237
70
FIG. 5-36
NOTE: Failure of fuse, B-1, is usually caused from
incorrect polarity (such as reversed cables
when using a booster battery). Failed fuse
will not allow battery to be charged during
normal operation.
IMPORTANT: Fuses are of specific amperage ca-
pacity for the circuit in which they are
located. Do not replace fuses with un-
authorized parts.
B-1
B-2
