ISHIDA IGB-60 - C1 Mode: Country, Scale, Zero, Span

Manual No. 085-3435-07 12/45 IGB/IGX Series (Overseas Specifications) Service Manual
2.2 C1 Mode (Country No., Scale No., Zero point, Span adjustment)
2.2.1 Country No. Table
Country Name USA 1 EU AUS ASIA USA 2 JPN
IDV
SET
Country Code 0 1 2 3 4 5 6 7 8 9 10 99
ADRS POS WGT Function Default Data (Change not allowed)
112 A H Start width 2 2 2 2 2 2 2 2 2 2 4 -
B H Stable/Re-stable count 3 3 3 3 3 3 3 3 3 3 3 -
113 A H Stable/Re-stable width 4 4 4 4 4 4 4 4 4 4 4 -
B H
Re-stable operation start width
4 4 4 4 4 4 4 4 4 4 4 -
114 A 1 Zero point mark
2 Over-scale display
4 Display less than true zero
8 Decimal point display
2 8 0 8 2 8 0 8 4 0 5 -
B 1 Over-scale range
2 Tare subtraction
4 Tare clear with ZERO key
8 Zero suppress
0 6 6 0 0 6 6 0 0 6 0 -
115 A 1 Key-in tare subtraction
2 Zero tracking
4 Micro weight follow-up
8 Unstable width
0 0 0 0 0 0 0 0 0 0 4
-
B 1 PLU display (IGB only)
2 Stable display (IWB only)
4 Reserved
8 Reserved
0 6 6 6 4 6 6 6 5 5 5
-
Note
1. By setting the country code, weighing conditions will function based on the default data from
address 112 to 115.
2. The data is set to meet certified conditions for each country, so there is no need to change the
data.
3. Position “A” indicates the upper position of one-byte data, and “B” indicates the lower position.
4. As for Weight, a function is selected with “1”, “2”, “4”, and “8” in bit unit, and “H” indicates
Hexadecimal data.
5. Individual setting value “99” cannot be entered. (Displayed only when settings are changed in C7
mode)
6. “USA 2” code is settings to allow changing between “lb” and “kg” at anytime even in cases other
than a stable condition at zero point. (“USA 1” can change between “lb” and “kg” only when the
condition is stabilized at zero point)
When using this function, a maximum of 0.2e error may occur in weighing immediately after the
change. This error is calibrated by zero point adjustment (or zero tracking), and an accurate
weighing is guaranteed.
When selecting the weighing capacity exclusively for either “lb” or “kg”, use “USA 1”.
Reference
Ref er enc
e
Refer to “Weighing Condition Data Table” for detailed function selection.
