ISHIDA IGB-60 - Page 26

Manual No. 085-3435-07 25/45 IGB/IGX Series (Overseas Specifications) Service Manual
Address Item Data Range Remarks
101 100A and 100B check data
(Writing twice)
-
102A Selection of ON/OFF key function (bit 0)
Selection of Preset auto call-up function (bit 1)
Selection of 16/24 digit printer (bit 2)
Selection of Date print function (bit 3)
0 to 1 (F1)
0 to 1 (F2)
0 to 1 (F3)
0 to 1 (F4)
Data set in Setup
Mode of Operation
Manual.
102B Selection of Preset No. print function (bit4)
Selection of single/consecutive chit print (bit5)
Selection of Tare amount print function (bit6)
Selection of Upper/Lower limits print function (bit7)
0 to 1 (F5)
0 to 1 (F6)
0 to 1 (F7)
0 to 1 (F8)
Reference
Ref er enc
e
Refer to IGB/IGX
Operation Manual.
103A Baud rate setting (bit 0 to 3) 0 to F (F9)
103B Output message specification (bit 4 to 7) 0 to F (F10)
104A Data output method (bit 0 to 3) 0 to F (F11)
104B Data output condition (bit 4 to 7) 0 to F (F12)
105A Contact output signal setting (bit 0 to 3) 0 to F (F13)
105B Contact input signal setting (bit 4 to 7) 0 to F (F14)
106A High-level buzzer output setting (bit 0 to 3) 0 to F (F15)
106B Built-in buzzer selection function (bit 4 to 7) 0 to F (F16)
107A Automatic power off setting (bit 0 to 3) 0 to 6 (F17)
107B Reserved
108 to 109 Check sum from 102 to 107 -
110 to 115 Weighing condition setting data Refer to Weighing
condition setting table.
116A Country code (Refer to Country code table) 0 to F (Default 10: Japan)
116B Reserved 0
117A Reserved 0
117B Reserved 0
118 to 120 A/D zero point data (adref) 24 bit
121 to 123 A/D calibration data (adwidth) 24 bit
124
Weighing capacity setting (Refer to Capacity setting
table)
00 to 99 (Default 1: 60kg)
125A JAPAN only 0 to F
125B Span adjusted flag 5H or others
5H=OK
Others=Error
126, 127 Check sum from 100 to 113. -
