Manual No. 085-3435-07 28/45 IGB/IGX Series (Overseas Specifications) Service Manual
IGB Series Service Parts List
No. Part Name Remark Part No. Q'ty
1 CASE FRONT 900-0756-05 1
2 CASE REAR ’BATTERY’ 900-0753-04 1
3 COVER ’BATTERY’ 900-0754-08 1
6 BRACKET 900-0725-00 1
7 BRACKET ’DISPLAY’ 900-0726-03 1
10 WASHER ’RUBBER’ 900-0748-05 2
11 FILTER ’DISPLAY’ 900-0755-01 1
12 SHEET ’DISPLAY’ 60kg Varied per country 1
12 SHEET ’DISPLAY’ 150kg Varied per country 1
14 SHEET ’COVER’ 900-0793-03 1
15 SPRING 1 900-1013-05 1
16 SPRING 2 900-1014-18 1
17 CUSHION BATTERY 900-0319-01 4
18 NAME PLATE ’SPEC.’ 60kg Varied per country 1
18 NAME PLATE ’SPEC.’ 150kg Varied per country 1
19 PWB PS-018 900-0677-04 1
20 PWB PS-019 900-0767-06 1
22 CABLE LOCKING (PG-11) 900-0758-02 1
23 HARNESS 'S2' GND 900-0772-05 1
25 SCREW M 4×45 900-0842-02 2
26 SHEET 900-1064-05 2
31 SIDE COVER 900-0037-11 1
32 POLE STAND 900-0032-49 1
33 RUBBER RING 900-0207-07 1
34 PLATTER 072-8847-05 1
35 SHEET ’PLATTER ’ 900-0100-02 1
36 PLATE SUPPORT 900-0021-11 1
37 BASE 900-0020-35 1
38 FOOT ’LEVEL’ 900-0022-05 4
39 PLATE A ’LEVEL’ 900-0222-03 1
40 LEVEL UNIT ASS. 900-0315-15 1
41 BRACKET ’LEVEL’ 900-0010-01 1
42 LOAD CELL (LOC-ISS10-100kg) 60kg 900-0815-01 1
42 LOAD CELL (LOC-ISS10-300kg) 150kg 900-0816-05 1
Note: Part numbers may change without notice due to product improvements.
