Manual No. 085-3435-07 4/45 IGB/IGX Series (Overseas Specifications) Service Manual
Item Contents
IGB Series IGX Series
Model Name
IGB-60 IGB-150 IGX-60 IGX-150
Power Source
Two dry batteries (not included with the
machine), or optional AC adapter
[Battery Life]
Conditions: No option, Temperature 20°C,
Relative humidity 60%RH
Two “D” size alkaline batteries (Approx. 500H
continuous use)
The required transformer is provided for
each 100VAC, 120VAC, 220VAC, or
240VAC.
Power Consumption 25mA
100VAC: 57mA
120VAC: 46mA
220VAC: 28mA
240VAC: 23mA
Display LCD
Numerics: 6 digits, Height 25mm
Mark: Battery. Zero point, Now subtracting
tare, Stable, Weight unit (kg･lb), Over,
Under, Accept
VFD
Numerics: 5 + 1/2 digits, Height 29mm
Mark: Zero point, Now subtracting tare
LED
Over, Under, Accept
Tare Subtraction Key-in tare
Preset tare
Preset Function [Program Mode] 10 PLUs from PLU 1 to PLU 10 (Tare weight, Upper limit, Lower limit)
Upper Limit Range More than the lower limit, within 5 digits (99999)
Lower Limit Range Less than the upper limit, (5 digits in case of the upper limit = 0)
Auto Power Off [Setup Mode] None/10min./ 20min./ 30min./
40min./ 50min./ 60min.
No
Auto Preset Call-up [Setup Mode] Function “Yes”/”No” selection (PLU 1 is called up when the power is ON.)
Battery Check Mode Yes No
Buzzer No [Setup Mode]
ON/OFF Switch No [Setup Mode]
Option AC adapter (Dealer option)
