Chapter 1 INSTALLATION
1-8 IP-EMZ Operation Manual
1.6 HARDWARE INSTALLATION
1.
Install the main body to be able to see
the display clearly and perform the key
operation easily.
2.
Connect the cable of the scale unit with
the main body.
Connection or separation in the
power-on state may cause damage.
3.
Turn the level adjuster so that the unit
is horizontally installed. To install the
scale unit horizontally, turn the level
adjuster until the bubble locates at the
center of circle of the level gauge.
If this adjustment is not performed
accurately, a weighing error may occur.
Scale unit
Bubble
Circle
Level adjuste
Level gauge
4.
Make sure that the machine is
grounded at the power supply outlet.
5.
Insert the power plug into the outlet.
(CAN,USA)
(EU)
To Next Page
