Chapter 1 INSTALLATION
1-4 IP-EMZ Operation Manual
1.2 NAME OF EACH PART
1.2.1 FRONT VIEW
Touch panel
Stroke keys
Level gauge
Scale unit
Power switch
Level adjuste
r
Label outlet
Label cassette
Brightness
adjustment dial
Lighter
Darker
1.2.2 REAR VIEW
Rear Connectors
(Located in the rear cover)
