Chapter 1 INSTALLATION
1-2 IP-EMZ Operation Manual
1.1 SPECIFICATIONS
No. Item Specifications
1 Operating environment
1.1 Temperature range
-5°C - 40°C
1.2 Operating humidity 20% - 85% (Non condensing)
2 Outer dimensions
2.1 Main body W285 × D368 × H645mm
2.2 Scale unit W300 × D270 × H88mm
3 Mass
3.1 Main body 19kg
3.2 Scale unit 6kg
4 Power supply
CAN, USA:
EU:
AC110-120V 50/60Hz 4A
AC230V 50/60Hz 4A
5 Weighing capacity
CAN:
6kg/15kg
Graduation: 0.002kg (0 –6kg),0.00 5kg (6- 15kg)
15lb/30lb
Graduation: 0.005lb (0 – 15lb),0.01lb (15 – 30lb)
USA:
15lb/30lb
Graduation: 0.005lb (0 – 15lb),0.01lb (15 – 30lb)
EU:
3kg/6kg
Graduation: 0.001kg (0 –3kg),0.00 2kg (3- 6kg)
6 Weighing accuracy
1/3000
7 Display unit
10.4-inch TFT color liquid crystal VGA with backlight
(640 × 480 dots)
8 Printing method
Direct thermal method
9 Thermal head
LH4114K (TDK) 3-inch (640 dots), 8 dots/mm
10 Print speed
100mm/sec
11 Effective print size
78mm
12 Label size
12-1 Label width 30 - 80mm
12-2 Label length 30 - 150mm
12-3 Backing paper width 32 - 82mm
13 Label diameter
13-1 Core inner diameter
76mm
13-2 Max. outer diameter
2240mm
14 Keys
14-1 Touch panel 212mm × 159mm
14-2 Stroke key 24 keys
15 I/O
Ethernet:1ch
RS-232C:2ch
PCMCIA:2ch
I2NET:2ch(ISHIDA Original Protocol)
16 Program storage medium
16-1 Flash ROM (1MB) Boot program
16-2 Compact Flash (32MB) OS + Application program
17 Memory capacity
*The registration number varies depending on the total memory
capacity.
17-1 PLU master 511 characters, 4,000 PLUs, 5 prices
17-2 Additive master 511 characters, 9,999 additives
17-3 POP master 39 characters, 999 POPs
17-4 Comment master 511 characters, 99 comments
17-5 Origin master 39 characters, 9,999 origins
17-6 Storage temperature master 119 characters, 99 temperatures
17-7 Storage method master 119 characters, 99 methods
17-8 Free master 1 511 characters, 99 messages
17-9 Free master 2 511 characters, 99 messages
17-10 Free master 3 511 characters, 99 messages
