Inspection and Installation
• YES: indicates reset the LAN to the default settings.
5. After setting, press [Esc] to exit.
View LAN Interface Information
The operation steps to view the LAN interface information are as follows.
1. Press [Shift]+[Display] (System) to enter into the system menu interface.
2. Use left and right keys or rotate the knob to select Comm and press [Enter]
key to confirm.
3. Use left and right keys or rotate the knob to select LAN and press [Enter]
key to confirm.
The first displayed menu item Lan Info is to view the LAN interface
information.
4. Press [Enter] key to confirm.
5. Use left and right keys or rotate the knob to view the LAN interface informa-
tion. Refer to System Menu for more information.
6. After setting, press [Esc] to exit.
2.7.2.1 Web Interface
The instrument has a built-in Web interface for monitoring and controlling the in-
strument via a Web browser. To use the Web interface, connect the instrument
and PC over LAN and enter the instrument's IP address into the address bar at
the top of your PC's Web browser, you can access the front panel control func-
tions including the LAN configuration parameters.
• In Web control mode, the instrument panel operation is still valid.
• The instrument supports simultaneous connection to up to 6 computers. If there
are more connections, the instrument performance will be reduced.
As shipped, the login password of the Web interface defaults to 12345678. To
change the password, click the Security button in the navigation bar on the left
side of the window after login.
Enter the password and then click the LOGIN button, the Web interface will ap-
pear in the browser as shown below. The following figure is just as an example
and the Web interface of different models are different. The actual shown page
shall be subject to the connected instrument.
Copyright © Itech Electronic Co., Ltd.
30
