ITRON ACE6000 User Manual

Erreur ! Utilisez l'onglet Accueil pour appliquer Heading 1 au texte que vous souhaitez faire apparaître ici.
Enclosure type
Panel mounting DIN compliant
Environmental protection
IP 54
Operating temperature
Range -40°C to +70°C
Relative Humidity
< 75% (maximum 95%)
Net weight
1.1kg
Maximum meter dimensions (W x H x D)
Meter body
152 x 238 x 68mm
With short terminal cover
241 x 173 x 74mm
With long terminal cover
301 x 173 x 78mm
Direct connection specifications
Voltage
3 x 57.7/100V up to 3 x 277/480V auto ranging
Current
Nominal (Ib)
5A
Maximum (Imax)
100A
Accuracy
Active energy
Class 1
Reactive energy
Class 2
Transformer connection specifications
Voltage
3 x 57.7/100V up to 3 x 277/480V auto ranging
Current
Nominal (Ib)
1A to 5A
Maximum (Imax)
10A
Accuracy
Active energy
Class 1 / Class 0.5
Reactive energy
Class 2
5.3. Meter support tools
The ACE6000 meters have an extensive range of optional facilities and settings, enabling them to be configured
to suit individual requirements. In general, a meter is fully configured and programmed for its intended application
prior to despatch from the factory.
However, some aspects of the configuration may be changed at any time using dedicated Windows™-based
support tools that typically communicate via the optical port on the front of the meter.
Support tool applications provide the following main features:
metering point management
configuration creation and editing
configuration programming and reading
meter data reading
meter firmware upgrading
The following support tools are currently available:

ITRON ACE6000 Specifications

General

Voltage	230V AC
Frequency	50/60 Hz
Display	LCD
Communication	RS-485
Temperature Range	+55°C
Current	5A
Frequency Range	45Hz to 65Hz
Storage Temperature	+70°C
Humidity	95% RH (non-condensing)
