ITRON ACE6000 User Manual

21
General
Parameter
Description
Data
Meter Type
ACE6000
Connection wiring
3 or 4 wires
Connection configuration
Direct or Transformer
Terminal wiring
VDE (asymmetrical)
Metrology
Four quadrant
Active and Reactive
(import and export)
Metrology sensors
Mutual Conductance Transformers
Registering modes
4 selectable algorithms
Ferraris
Static
Net result
Anti-fraud
Direct connection accuracy
i.a.w. IEC62053-21
Class 1
Transformer connection accuracy
i.a.w. IEC62053-21, 22
Class 1 / Class 0.5
Voltage
Parameter
Details
Reference voltage
3 x 57.7/100V up to 3 x 277/480V
auto ranging
Operating voltage
-20% to + 15% Un
Peak voltage
Ph to Ph and Ph to N
3 x 277/480V + 15% auto ranging or
3 x 500/866V for 10secs mono range
Voltage Interruptions
1 second
Direct connection current
Parameter
Details
Nominal current (Ib)
5A
Maximum current (Imax)
100A
Transformer connection current
Parameter
Details
Nominal current (Ib)
1A to 5A
Maximum current (Imax)
10A
6. Technical specification

ITRON ACE6000 Specifications

General

Voltage	230V AC
Frequency	50/60 Hz
Display	LCD
Communication	RS-485
Temperature Range	+55°C
Current	5A
Frequency Range	45Hz to 65Hz
Storage Temperature	+70°C
Humidity	95% RH (non-condensing)
