ACE6000 User Guide
22
Direct connection starting current and short-time over current
Parameter
Details
Starting current
Ib/250
Maximum load capacity (over half-
cycle)
30Imax
Transformer connection starting current and short-time over current
Parameter
Details
Class 1
Ib/500
Class 0.5 / Class 0.2
Ib/1000
Maximum load capacity 0.5 secs
20Imax
Voltage Circuit Power Consumption
Parameter
Details
Voltage per phase
<2W
Apparent power per phase at Un
<10VA
Current Circuit Power Consumption
Parameter
Details
Burden (per phase) at Ib
<1VA
Display
Parameter
Description
Data
Type
Liquid Crystal Display (LCD)
Digit height
Main
8mm
Digit height
OBIS code
6mm
Resolution
Number of digits
8
Communications
Parameter
Description
Data
Optical communications
i.a.w IEC62056-21
i.a.w IEC62056-47,53,61 & 62
Read out only
Read/Write
Mode of operation
Read out mode C
Meter Constant
Direct connection type
1000 pulses per kWh
Transformer connection type
10000 pulses per kWh
Serial Data Communications
RS232 or RS485
1 x RJ45 connector fitted for
RS232
2 x RJ45 connectors fitted for
RS485 (daisy-chaining)
Baud rate
9600 up to 19200
Supported protocols
DLMS/Cosem
IEC62056-47,53,61 & 62
Communication media types
TCP
With external LAN modem

ITRON ACE6000 Specifications

General

Voltage	230V AC
Frequency	50/60 Hz
Display	LCD
Communication	RS-485
Temperature Range	+55°C
Current	5A
Frequency Range	45Hz to 65Hz
Storage Temperature	+70°C
Humidity	95% RH (non-condensing)
