ACE6000 User Guide
24
Parameter
Description
Data
auxiliary circuits
1.2/50μsecs
Source impedance 42 ohms
Electrostatic discharge
Electrostatic discharge according to
IEC61000-4-2
Contact discharge
8kV, 10 cycles
Air discharge
15kV, 10 cycles
Immunity to RF fields
RF fields i.a.w. IEC61000-4-3
With current
80MHz to 2GHz
10V/m
Without current,
80MHz to 2GHz
30V/m
Fast transient burst
main circuits
Fast transient burst i.a.w. IEC
61000-4-4
4kV
common-mode and pseudo
differential
Fast transient burst
auxiliary circuits
Fast transient burst i.a.w. IEC
61000-4-4
2kV
common-mode
Radio Interference
RF suppression
CISPR22 Class B
Weight and Dimensions
Parameter
Description
Data
Weight
1.1kg nominal
Dimensions
(width x height x depth)
Without terminal cover
152 x 238 x 68mm
With short terminal cover
241 x 173 x 74mm
With long terminal cover
301 x 173 x 78mm

ITRON ACE6000 Specifications

General

Voltage	230V AC
Frequency	50/60 Hz
Display	LCD
Communication	RS-485
Temperature Range	+55°C
Current	5A
Frequency Range	45Hz to 65Hz
Storage Temperature	+70°C
Humidity	95% RH (non-condensing)
