Important
: Required Open flow rates may be dif
ferent than those shown here.
9.
Enter 20 for
Flow
>
Check %
.
Important
: Required Check flow rates may be dif
ferent than those shown here.
10.
Select
1/10 cuft
for
Hand Size
.
Proving the Intelis Gas Meter
Intelis Gas Meter Installation Guide TDC-1782-002
49
Proprietary and Confidential
52
54
