Figure 46
112863
TIMING DIAGRAMS FOR THE FOLLOWING APPLICATIONS:G
DRIVE - GRIFFON - SPRINKLER
1. Camshaft - 2. Camshaft rpm sensor - 3. Camshaft flywheel - 4. Engine flywheel -
5. Crankshaft rpm sensor fitted on the flywheel casing
SECTION 4 - OVERHAUL AND TECHNICAL SPECIFICATIONS 25
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
