Design and Function
26
3.2.4 Material and tool changer
The material and tool changer is not accessible to the user. This chapter is only intended to
explain how the device is equipped with blocks and tools.
The user can conveniently equip the material and tool changer via the loading aid. The
processing and changer arm provides the tool holders (pos. no. 4 in the illustration, for tools)
and block holders (pos. no. 5 in the illustration, for blocks) from the block and tool changer
cartridges at the loading aid, where they can be removed, loaded and inserted.
The illustrations of the block and tool holders in these Operating Instructions may differ
slightly form the actual block and tool holders.
2
3
1
10
96
7
45
8
