Design and Function
27
No. Description Function
1 Camera below cover Identification of tools and blocks via
the data matrix code for later use in a
milling job.
2 Block cartridge (5 x) • Reception for one block holder with
one block.
• The device has space for five blocks.
3 Tool cartridge (4 x) • Reception for one tool holder
• 6 milling/grinding tools and a
cleaning tool. Make sure that the
cleaning tool is inserted into the
tool holder slot marked with “II”.
The second position must be left
empty.
4 (with
9 + 10)
Tool holder • Component for loading up to two
tools by the user.
• Arrow (9) shows the correct loading
direction for the tool holder (4) in
the loading aid.
• The hooks (10) must point upwards
when loading.
5 (with
6- 8)
Block holder • Component for loading a block by
the user.
• Figures of the block (6) show the
correct loading direction of the
block in the block holder.
• Arrow and description (7) show the
correct loading direction of the
block holder (5) in the loading aid.
• The hooks (8) must point upwards
when loading.
