Jacobsen AR-3 User Manual

6-4 4181384 First Edition
HYDRAULICS
6
Repair Specifications
Specifications
Tandem Pump—End Cap-to-Pump
Body Screw Torque
lb-ft (N·m) 32—36 (43—49)
Lift Valve—Solenoid Coil Torque
lb-ft (N·m) 3 (4)
Lift Valve—Relief Valve Torque
lb-ft (N·m) 37 (50)
Lift Valve—Check Valve Torque
lb-ft (N·m) 30 (40)
Lift Valve—Orifice Plug Torque
lb-ft (N·m) 2 (3)
Lift Valve—Hollow Hex Plug Torque
lb-ft (N·m) 5 (6.5)
Flushing Valve—
Check Valve Torque
lb-ft (N·m) 37 (50)
Flushing Valve—
Sequence Valve Torque
lb-ft (N·m) 37 (50)
Flushing Valve—M5 x 1.00
Diameter Orifice Plug Torque
lb-ft (N·m) 2 (3)
Flushing Valve—M5 x 0.50
Diameter Orifice Plug Torque
lb-ft (N·m) 1.7 (2.5)
Mow/Brake Valve—
Mow Solenoid Valve Torque
lb-ft (N·m) 20 (27)
Mow/Brake Valve—
Brake Solenoid Valve Torque
lb-ft (N·m) 22 (30)
Mow/Brake Valve—
Load Control Valve Torques
lb-ft (N·m) 50 (68)
Mow/Brake Valve—
Relief Valve Torque
lb-ft (N·m) 37 (50)
Mow/Brake Valve—
Solenoid Coil Torque
lb-ft (N·m) 3 (4)
Mow/Brake Valve—
Hollow Hex Plug Torque
lb-ft (N·m) 5 (6.5)
Mow/Brake Valve—
Hollow Hex Plug Torque
lb-ft (N·m) 37 (50)
Hydraulic Oil Tank Capacity
gal (L) 6.6 (25)
