Jacobsen AR-3 - Repair Specifications; Specifications; Test and Adjustment Specifications

4-4 4181384 First Edition
ELECTRICAL
4
Specifications
Test and Adjustment Specifications
Repair Specifications
Specifications
Resistance Across Solenoid Coil—12-Volt
Solenoid Coils at 68°F
ohms 10.43 ±10%
Resistance Across Solenoid Coil—24-Volt
Solenoid Coils at 68°F
ohms 41.74 ±10%
Fuel Shutoff Solenoid Resistance
Between Terminal 1 and Ground
ohms 15.58
Fuel Shutoff Solenoid Resistance
Between Terminal 3 and Ground
ohms 0.375
Fuel Level Sender Resistance Between
Terminals at empty position
ohms 180
Fuel Level Sender Resistance Between
Terminals at empty position
ohms 4.0
Specifications
Solenoid Coil Retaining Nut Torque lb-in. (N·m) 36 (4.1)
