SPECIFICATIONS AND GENERAL INFORMATION
4181384 First Edition 2-7
2
Specifications
Quick Reference Specifications
Electrical
Test Specifications
Resistance Across Solenoid Coil—
12-Volt Solenoid Coils @ 68°F
ohms 10.43 ± 10%
Resistance Across Solenoid Coil—
24-Volt Solenoid Coils @ 68°F
ohms 41.74 ± 10%
Fuel Shutoff Solenoid Resistance
between Terminal 1 and Ground
ohms 15.58
Fuel Shutoff Solenoid Resistance
between Terminal 3 and Ground
ohms 0.375
Fuel Level Sender Resistance
between Terminals at EMPTY
position
ohms 180
Fuel Level Sender Resistance
between Terminals at FULL Position
ohms 4.0
Repair Specifications
Solenoid Coil Retaining Nut Torque lb-in. (N·m) 36 (4.1)
