2-10 4181384 First Edition
SPECIFICATIONS AND GENERAL INFORMATION
2
Cutting Units
Accessories and Miscellaneous
Repair Specifications—AR-3
Deck Drive Motor Housing-to-Front
Cover Screw Torque
lb-ft (N·m) 37 (50)
Cutter Blade Retaining Screw
Torque
lb-ft (N·m) 70 (95)
Fuel Tank
Capacity gal (L) 6.6 (25)
OPS
M10 Mounting Hardware Torque lb-ft (N·m) 34 (46)
M12 Mounting Hardware Torque
lb-ft (N·m) 58 (79)
Front Tires
Size 20 x 12.00-10
Type Turf Trac, 4-ply
Air Pressure
psi (bar) 14—20 (97—138)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
Rear Tire
Size 20 x 12.00-8
Type Turf Trac, 4-ply
Air Pressure
psi (bar) 14—22 (97—152)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
