9-2 4181384 First Edition
ACCESSORIES AND MISCELLANEOUS REPAIR
9
Specifications
Repair Specifications
Fuel Tank
Capacity gal (l) 6.6 (25)
OPS
M10 Mounting Hardware Torque lb-ft (N·m) 34 (46)
M12 Mounting Hardware Torque
lb-ft (N·m) 58 (79)
Front Tires
Size 20 x 12.00-10
Type Turf Trac, 4-Ply
Air Pressure
psi (kPa) 14—20 (97—138)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
Rear Tire
Size 20 x 12.00-8
Type Turf Trac, 4-Ply
Air Pressure
psi (kPa) 14—22 (97—152)
Mounting Bolt Torque
lb-ft (N·m) 85—95 (115—128)
